Description
Please be advised all Hokuyo components not in stock now have a 10-12 month lead time
- Small, accurate, high-speed scanning laser range finder
- Obstacle detection and localization of autonomous robots
- Light source: Laser semiconductor (905nm)
- Scan speed: 25ms (Motor speed 2400rpm)
- Detection distance: 60m (maximum)
The Hokuyo UST-20LX Scanning Laser Rangefinder is a small, accurate, high-speed device for obstacle detection and localization of autonomous robots and automated material handling systems. This model uses Ethernet interface for communication and can obtain measurement data in a wide field of view up to a distance of 20 meters with millimeter resolution. Due to its low power consumption, this scanner is able to be used on battery-operated platforms.
This sensor uses a laser source to scan 270° field of view. Positions of objects in the range are calculated with step angle and distance. Sensor outputs these data through communication channel.
Applications
- Navigation and obstacle detection (Guide path planning for mobile robots and autonomous systems)
- Object positioning (control docking processes of AGVs, AGCs)
- Object Profiling (cargo containers, pallets for loading & unloading)
- Object measurement and detection (volume of packages, pallets, flow measurement of bulk materials)
- Area monitoring (building security and entrance ways)
- Size: 50mm x 50mm x 70mm (sensor only)
- Weight: 130g (excluding cable)
ZIP File
- Supply voltage: 12VDC/24VDC (operation range 10 to 30V ripple within 10%)
- Supply current: 150mA or less (during start up 450mA is necessary)
- Accuracy: ±40mm
- Repeated accuracy: σ< 30mm
- Scan angle: 270°
- Scan speed: 25ms (Motor speed 2400rpm)
- Angular resolution: 0.25°
- Protective structure: IP65
- Interface: Ethernet 100BASE-TX
- Surrounding intensity: Less than 15,000lx
- Material front case: Polycarbonate
- Rear case: Aluminum
- Ambient temperature: -10°C to +50°C
- Ambient humidity: Below 85%RH (without dew, frost)
- Storage temperature: -30°C to +70°C
- Storage humidity: Below 85%RH (without dew, frost)
- Shock resistance: 196m/s2 (20G) X,Y and Z direction 10 times
- Input: IP reset input, photo-coupler input (current 4mA at ON)
- Output: Synchronous Output, photo coupler open collector output 30VDC 50mA (maximum)
- LED display: Power supply LED display (Blue): Blinks during start up and malfunction state
- Start up time: Within 10 sec (start up time differs if malfunction is detected during start up)
Light source
- Laser semiconductor (905nm)
- Laser class 1 (IEC60825-1:2007)
Detection range
- 0.06m to 20m (white Kent sheet)
- 0.06m to 8m (diffuse reflectance 10%)
- Maximum detection distance: 60m
Vibration resistance
- 10 to 55Hz double amplitude of 1.5mm for 2hrs in each X, Y, and Z direction
- 55 to 200Hz 98m / s2 sweep of 2min for 1hr in each X,Y and Z direction
- (Operating) 55 to 150Hz 19.6m / s2 sweep of 2min for 30min in each X,Y and Z direction
EMC standards
EMI
- EN61326-1: 2013
- EN55011: 2009 + A1: 2010
EMS
- EN61326-1: 2013
- EN61000-4-2: 2009
- EN61000-4-3: 2006 + A1: 2008 + A2: 2010
- EN61000-4-4: 2012
- EN61000-4-6: 2009
- EN61000-4-8: 2010
